SPECIFICATION
FUNCTION	Value
Input Voltage Range	1ψ: 220V ± 10%
Motor Output Power	350/650W
Motor Rated Speed	7000/3500 RPM
Pulley Size Range	65-85mm
External LED Socket(DC12V)	Y
Needle Up/Down Positioning	Y
Max. Speed Adjustment	Y
Soft Start	Y
Target sitiching	Y
Reverse After Thread Trimming	Y
One Shot Position(Fast positioning)	Y
FET Over Current Protection	Y
Material Counter Function	Y
Diagnostic Mode to Inspect I/O Condition	Y
Error History Mode(Record Previous 6 times)	Y
Edge Sensor Port	2
Input Port(By customers requirement)	8
Output Port(By customers requirement) For cylinder only. DC24V/100mA for each cylinder.	5
Standing Operation Pedals(PK70/PK71)	Option
