| SV-260 規格 |
|
FUNCTION
|
Value
|
|
Input Voltage Range
|
1 ψ : 220V ± 10%
|
|
Motor Output Power
|
750W
|
|
Motor Rated Speed
|
3000 RPM
|
|
Pulley Size Range
|
65-140mm
|
|
Needle Up/Down Positioning
|
Y
|
|
Max. Speed Adjustment
|
Y
|
|
Soft Star
|
Y
|
|
Trimmer/Wiper
|
Y
|
|
Pressure Foot Lifting
|
Y
|
|
Inching
|
Y
|
|
Target Stitching
|
Y
|
|
Automatic Back-tacking
|
Y
|
|
Reverse after Thread Trimming
|
Y
|
|
Module/ Transistor Protection
|
Y
|
|
Material Counter
|
Y
|
|
Edge Sensor Input Ports No.
|
2
|
|
I/O Ports No.
|
18/ 8+1
|
|
With Standing Operation 3 Pedals
|
Y (With PK-70)
|
|
With Standing Operation 1 Pedal
|
Y (With PK-80)
|
|
With External Control Panel
|
Y (With C-200)
|
|
Diagnostic Mode (Inspect I/O Conditions)
|
Y
|
|
Display ERROR History Mode ( Record Previous 6 Times)
|
Y
|
|
Gross Weight
|
12Kg
|
|
Packing Dimensions
|
489L*426W*320H
|
