| SPECIFICATION |
|
FUNCTION
|
SV-520
|
SV-550
|
|
Input Voltage Range
|
1ψ: 220V ± 10%
|
1ψ: 220V ± 10%
|
|
Motor Output Power
|
450/550/750W
|
450/550/750W
|
|
Motor Rated Speed
|
3000/5000 RPM
|
3000/5000 RPM
|
|
Pulley Size Range
|
65-100mm
|
65-100mm
|
|
Needle Up/Down Positioning
|
Y
|
Y
|
|
Max. Speed Adjustment
|
Y
|
Y
|
|
Soft Star
|
Y
|
Y
|
|
Trimmer/Wiper
|
Y
|
Y
|
|
Automatic Back-tacking
|
Y
|
Y
|
|
Target Stitching
|
Y
|
Y
|
|
Reverse after Thread Trimming
|
Y
|
Y
|
|
FET Over Current Protection
|
Y
|
Y
|
|
Material Counter
|
Y
|
Y
|
|
The Diagnostic Mode to Inspect The I/O Status
|
Y
|
Y
|
|
The ERROR History Mode(6 records)
|
Y
|
Y
|
|
Total Weight
|
7.2~7.6Kg
|
7.2~7.6Kg |
|
Edge Sensor Port
|
2
|
2
|
|
Input Port
|
10
|
14
|
|
Output Port
|
5
|
8
|
|
Inching
|
Y
|
Y
|
|
One Shot Position
|
Y
|
Y
|
|
Standing Operation 3 Pedals
|
Option(PK-70)
|
Option(PK-70)
|
|
Standing Operation 1 Pedal
|
Option(PK-80)
|
Option(PK-80)
|
|
External Control Panel
|
Option(C-201)
|
Option(C-201)
|
